COMBUSTION SYSTEM

SWIRL COMBUSTION CHAMBER

BORE*STROKE(MM)

92*90

PISTON DISPLACEMENT(L)

0.598

RATED POWER

10HP

RATED SPEED(R/MIN)

2400

COMPRESSION RATION

22

FUEL CONSUMPTION(G/KW·H)

377

COOLING METHOD

WATER-COOLED

LUBRICATION METHOD

PRESSURE SPLASH

STARTING METHOD

HAND-CRANKING

NET WEGHT(KG)

96

PACKING SIZE(MM)

760*410*570
