DG6LE-3P

DG7250LE-3P

DG8250LE-3P

Frequency(Hz)

50/60

Voltage(AC)(V)

220/380;230/400;240/415

Voltage(DC)(V)

12

Current(A)

8.30

Engine speed(rpm)

3000/3600

Power factor(cosφ)

0.8

Net weight(kg)

115

125

130

Rated power(KW)

4.6/5.0

5.5/6.0

6.5/7.0

Starting system

Recoil manual start/optional electric start

Engine model

JT186FA(E)

JT188F(E)

JT192F(E)

Type

Single-cylinder,Vertical,4-Strock,Direct injection,Air-cooled diesel engine

Cooling type

Force air-cooled

Crankshaft direction

Clockwise from flywheel end

Rated Output(KW)

5.9/6.9

6.8/7.5

8.1/8.7

Bore*Stroke(mm)

86*72

88*75

92*75

Displacement(cc)

418

456

498

Fuel Tank Capacity(L)

15

Packing dimensions(L*W*H)mm

765*530*630

Lube-oil Capacity(L)

1.65
