DWP15CH(E)

DWP20CH(E)

DWP30CH(E)

Suction port diameter(inch)

1.5

2

3

Discharge Port Diameter(inch)

1.5

2

3

Total Head(m)

60

63

66.4

Flow Rate(m³/h)

19

27.8

38.38

Max suction head(m)

5

Overall dimensions(mm)

510*420*540

510*465*570

575*485*620

N.W/G.W(kg)

50/52

52/54

70/72

Starting Model

Recoil start/electric start

Engine Model

ETK178F(E)7HP

ETK186FA(E)12HP

Type

Single-cylinder,Vertical,4-Strock,Direct injection,Air-cooled diesel engine

Bore*Stroke(mm)

78*62

86*72

Engine Speed(rpm)

3600

Displacement(cc)

296

418

Continuous Output(KW)

4.4

6.9

Maximum Output(KW)

4.9

7.6

Cooling Type

Force air-cooled
